ZDF Series Single Fiber Separator

ZDF Series Single Fiber Separator ZDF Series Single Fiber Separator

ZDF Series Single Fiber Separator

Single fiber separator is mainly used for secondary breaking and screening of waste paper pulp, meanwhile, separating the light and heavy impurities from pulp. It also can be used as tail pulp treatment equipment.

We’re here to help:

Easy ways to get the answers you need.

Service Online

+86-371-55129198, +86-13783579051
+86-371-86138029
  • ZDF Series Single Fiber Separator
+86-371-55129198, +86-13783579051
+86-371-86138029



ZDF Series Single Fiber Separator

Features

  • 1. Mainly used for secondary breaking and screening of waste paper pulp, meanwhile, separating the light and heavy impurities from pulp.
  • 2. Specially designed cone structure can better break fiber, and can effectively separate and remove light and heavy impurities.
  • 3. Automatically discharge according to requirement, run reliably.

Technical Data

Type ZDF2 ZDF3 ZDF4 ZDF5
Diameter of Blade(mm) ɸ560 ɸ720 ɸ980 ɸ1100
Production Capacity(t/d) 30-50 60-80 100-180 165-265
Pressure of Input Pulp(Mpa) 0.2-0.3
Concentration of Input Pulp(%) 2.5-4.0
Power of Motor 37 55 90 110

Services

servicesOffering comprehensive technical and business consultation services;
Proposing the most suitable scheme and equipment for our clients;
Designing and fabricating targeted products according to the special requirements of clients;
Training periodically high qualified service technician.


Request for Quotation

You can get the price list and a Leizhan representative will contact you within one business day.
