BFW Series Chain Conveyor

Mainly used for conveying various kinds of pulp board, waste paper in bulk and in bundle which can be horizontal conveyor or inclined conveyor(<30°).
Intended particularly for loading of waste paper(loose or in bales) or chemical pulp into a pulper.

We’re here to help:

Easy ways to get the answers you need.

Service Online

+86-371-55129198, +86-13783579051
+86-371-86138029
  • BFW Series Chain Conveyor
  • BFW Series Chain Conveyor
  • BFW Series Chain Conveyor
  • BFW Series Chain Conveyor
+86-371-55129198, +86-13783579051
+86-371-86138029

Features

  • 1. Trough plate punch forming which high strength and excellent in crushing effect.
  • 2. Chain board adopts closed design to prevent material leaking.
  • 3. Two rows of idler traction chain and hollow roller shaft,and oil can be injected from pin roll to shaft sleeve and wear-resistant zinc-copper bushing.
  • 4. Two rows of chain adopt long axis to prevent chain running deviation.
  • 5. Chain wheel adopts cast steel to improve wear-resistant.
  • 6. Raw material feeding plate adopts V design( more than effective conveying width 400mm) to improve raw material throughput.
  • 7. Orbit type running,operate steadily and reliably, with low friction and low power consumption.

Technical Data

Technical Data of BFW Series Chain Conveyor:

chain plate Width (mm) 1200 1400 1600 1800 2000 2200 2400 2600
Feeding Capacity (m3/h) 60-220 80-255 95-300 110-345 140-390 160-430 200-500 240-600
Conveying Materials waste paper /pulp board
Max.Limit of Material (mm) 1000 1200 1400 1600 1800 2000 2200 2400
Motor power(Kw) 5.5 7.5 11 5 18.5 22-30 30-45 37-55

Work Principle

The Chain conveyor is mainly composed of driving device,tension device, link Plates, chain wheel and rack. The machine adopts chain to drive through plate to transport raw materials into the drum pulper for pulping. It is the best choice of waste paper and pulp plate conveying equipment.

In order to meet the needs of the users and technical layout requirements, the transmission installation of chain conveyor is divided into left type and right type(look up along the material running direction, transmission installation in the right of the machine is right type, Otherwise for the right type). Customer can chose the chain conveyor installation types according to the Process design requirements. When customer place an order for chain conveyor, the left or right type should be indicated in the contract.

Services

serviceAs to the design, basic dimensions and parameters may differ and can be adapted to particular projects. Waste paper (loose or in bales), respectively chemical pulp, is loaded in a hopper and from here conveyed by means of a conveying chain or a band to its discharging point where falling into a pulper chest.
