CSYTS Series Drum Screen for Coarse Screening

CSYTS Series Drum Screen for Coarse Screening

CSYTS Series Drum Screen for Coarse Screening is mainly used in the end stage of coarse screening in the waste paper pulping process, to clean the larger light impurities in the pulp, and to separate the pulp from the light impurities.

We’re here to help:

Easy ways to get the answers you need.

Service Online

+86-371-55129198, +86-13783579051

leizhanmachine@gmail.com

+86-371-86138029

+86-371-55129198, +86-13783579051

leizhanmachine@gmail.com

+86-371-86138029

CSYTS Series Drum Screen for Coarse Screening

Features

1. It is mainly used in the end stage of coarse screening in the waste paper pulping process, to clean the larger light impurities in the pulp, and to separate the pulp from the light impurities.
2. The pulp enters the Drum Screen after passing through the preceding equipment, and the accept enters the next process after passing through the screen slot.The light impurities are gradually led to the outlet and discharged continuously under the action of high-pressure flushing water and the internal structure of the drum.
3. It has the advantages of good screening and separation effect, low power consumption, simple structure, convenient maintenance, high impurity purity and less fiber loss, etc.
4. It is an replace product of Kangbi Screen, Reject Separator and Vibrating Screen.

Technical Data

Model	CSYTS850	CSYTS1500
Drum diameter(mm)	ɸ850	ɸ1500
Throughput(L/min)	3000-5000	6000-8000
Motor power(KW)	4	15
